Specifications
NUMBER OF INPUT CHANNELS 8 (XY mic capsule, 1-4, A, B)
NUMBER OF OUTPUT CHANNELS 2 (stereo headphone and stereo line)
Connectors
MIC IN ZOOM mic connector
INPUT 1-4 XLR jacks (2: HOT)
INPUT A/B XLR/TRS combo jacks (XLR: 2 hot, TRS: TIP hot)
USB USB Micro-B(audio interface, mass storage and Guitar Lab connection functions)Note: Use a USB cable that supports data transfer.Operation using USB bus power is possible.
REMOTE ZOOM BTA-1 or other dedicated wireless adapter
LINE OUT 3.5 mm stereo mini
PHONE OUT 3.5 mm stereo mini
PHANTOM POWER +24 V/+48 V (independent ON/OFF for INPUTS 1–4, A and B)
Recorder
RECORDING MEDIA Cards that support SD/SDHC/SDXC specifications
FORMATS WAV: 44.1/48/96 kHz, 16/24-bit, mono/stereoMP3: 128, 192, 320 kbps
MAXIMUM SIMULTANEOUS RECORDINGTRACKS 12 (MIC IN, backup recording, 1-4, A, B, and LR)
Audio interface
MULTITRACK MODE 44.1/48/96 kHz, 16/24-bit, 12-in/2-out
STEREO MIX MODE 44.1/48 kHz, 24-bit, 2-in/2-out
TUNER Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD
BUILT-IN SPEAKER 400 mW 8Ω mono speaker
DISPLAY 2.4" (320×240) full-color touchscreen LCD
POWER 4 AA batteries (alkaline, NiMH or lithium)AC adapter (ZOOM AD-17): DC 5 V/1AUSB bus power
Using XY mic, 44.1 kHz/24-bit (stereo × 1): about 15:00
The above values are approximate.
Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.
Note: When using a USB cable designed for recharging, audio interface, SD card reader and Guitar Lab connection functions cannot be used.
