Acoustic Principle Pressure Gradient
Active Electronics JFET impedance converter with bipolar output buffer
Capsule 1.00"
Polar Pattern Cardioid
Address Type Side
Frequency Range 20Hz - 20kHz
Output Impedance 100Ω
Maximum SPL 137dBSPL
Maximum Output Level 13.7mV (@ 1kHz, 1% THD into 1KΩ load)
Sensitivity -31.9dB re 1 Volt/Pascal (25.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz
Equivalent Noise Level (A-weighted) 5dBA
Power Options +24V phantom power+48V phantom power
